PVC Strip Curtain Cost UK (2026 Price Guide)
This guide covers the latest PVC strip curtain prices in the UK, including cost per square metre for warehouse, forklift, and freezer applications.
PVC strip curtains are one of the most cost-effective solutions for reducing heat loss, improving hygiene, and separating working environments — but prices vary depending on specification.
In this guide, we explain:
- Average PVC strip curtain prices per m² in the UK.
- What affects the total installed cost.
- Typical costs for warehouse and forklift doorways.
- How to get an instant online quote.
How Much Do PVC Strip Curtains Cost in the UK?
The average PVC strip curtain cost UK customers can expect in 2026 is:
- £35–£45 per m² for pedestrian-grade strip curtains
- £45–£55 per m² for medium-duty industrial curtains
- £55+ per m² for heavy-duty forklift strip curtains
- Freezer-grade and ribbed PVC typically add around 10%.
Prices depend on doorway size, overlap percentage, PVC grade, and suspension system.
For an accurate price, use our PVC strip curtain calculator or request a tailored quotation.
Prices shown are typical UK starting ranges excluding installation and may vary depending on doorway size, overlap, and specification.
PVC Strip Curtain Prices Per m² (UK Guide)
| Application Type | Strip Specification | Typical UK Cost Per m² |
| Pedestrian doorways | 200mm x 2mm PVC | From £35 per m² |
| Area division & screening | 300mm x 3mm PVC | From £45 per m² |
| Forklift traffic & loading bays | 400mm x 4mm PVC | From £55 per m² |
| Freezer & cold room PVC | Polar Grade | +10% premium |
| Ribbed PVC upgrade | Ribbed profile | +10% premium |
What Affects PVC Strip Curtain Cost in the UK?
-
Doorway Size
PVC strip curtain pricing is calculated by total material area and overall hardware costs.
Larger openings require:
- More PVC strips.
- Longer and stronger suspension rails.
- Greater overlap coverage.
Warehouse loading bays naturally cost more than small internal doorways.
-
Strip Width and Thickness
The most common industrial PVC strip curtain sizes are:
- 200mm x 2mm – pedestrian use
- 300mm x 3mm – factory or area screening
- 400mm x 4mm – forklift and heavy-duty access
Thicker PVC costs more because it is heavier, stronger, and more impact resistant.
Approximate PVC weight per metre:
- 200mm x 2mm = 0.5kg
- 300mm x 3mm = 1.1kg
- 400mm x 4mm = 1.9kg
-
PVC Grade
Different environments require different PVC formulations:
| PVC Grade | Best For | Cost Impact |
| Standard Clear | Warehouses, pedestrian doors | Lowest |
| Polar Freezer Grade | Cold rooms below 0°C | Slight premium |
| Anti-Static PVC | Cleanrooms, electronics | Moderate premium |
| Welding Grade PVC | Fabrication bays | Higher premium |
-
Strip Overlap Percentage
Overlap has a major impact on performance and cost.
Typical overlaps in the UK:
- 35% overlap – light-duty separation
- 50–60% overlap – most common industrial standard
- 75–90% overlap – maximum insulation and sealing
More overlap increases PVC usage, improving containment but raising cost.
-
Suspension Rail System
The suspension system affects pricing:
- Bullet rails (premium safety suspension system manufactured from plastic)
- Stainless steel rails (standard)
- Heavy-duty galvanised rails (forklift access)
- Sliding or retractable systems
Forklift curtains require stronger, heavier rail profiles.
PVC Strip Curtain Cost Examples (UK)
Small Pedestrian Doorway (1m x 2m) — From £70
Opening size: 1m x 2m
- 200mm x 2mm clear PVC
- Medium overlap (~50%)
- Stainless steel suspension
Medium Warehouse Opening (3m x 3m) — From £405
Opening size: 3m x 3m
- 300mm x 3mm PVC
- Medium overlap (~55%)
- Industrial rail system
Forklift Loading Bay (4m x 4m) — From £880
Opening size: 4m x 4m
- 400mm x 4mm heavy-duty PVC
- Medium overlap (~55%)
- Heavy-duty galvanised rail
All examples are indicative starting prices. Exact costs depend on specification.
Are PVC Strip Curtains Worth the Cost?
Yes — PVC strip curtains are one of the most cost-effective industrial doorway solutions.
They help reduce:
- Heat loss and energy waste.
- Dust and insect ingress.
- Temperature fluctuations
- Downtime from opening large doors.
They also improve hygiene and allow hands-free access.
How to Get an Instant PVC Strip Curtain Quote (UK)
To calculate your exact PVC strip curtain cost:
- Measure your doorway width and height.
- Confirm traffic type (pedestrian or forklift)
- Select PVC grade (standard or freezer-grade)
- Use our online pricing calculator.
Rayflex manufactures PVC strip curtains in the UK and supplies nationwide.
FAQs: PVC Strip Curtain Cost UK
How much does a PVC strip curtain cost in the UK?
Most PVC strip curtains cost between £35 and £55 per m², depending on thickness, overlap, and grade.
How much does a forklift PVC strip curtain cost in the UK?
Heavy-duty forklift strip curtains typically start from £55 per m², with complete 4m x 4m loading bay kits starting from around £880, depending on overlap and rail type.
Are freezer-grade PVC strip curtains more expensive?
Yes. Polar-grade PVC typically costs around 10% more due to specialist additives.
Do strip curtain kits include the rail?
Yes. Rayflex kits include suspension rails and pre-plated PVC strips.
Do thicker PVC curtains cost more?
Yes — PVC pricing is weight-based. Thicker strips cost more but last longer in high-traffic environments.
Get an Instant PVC Strip Curtain Price for Your Doorway
If you're planning a new installation or replacement, Rayflex can help you select the correct thickness, overlap, and grade.
Use our PVC strip curtain calculator for instant UK pricing or contact our expert team for tailored advice.
With over 50 years of UK manufacturing experience, we supply high-quality made-to-measure strip curtains nationwide.
